The SL-10 has been developed to suit small diameter machining requirements and offers accurate, efficient machining capabilities within a compact footprint.
The gang type tool post for face machining has a tool holder for turning and a cross drilling unit for multi-processing in a vertical layout. The 5-spindle cross drilling unit allows tool unit changes at four cartridge positions depending on the shape to be processed which offers wider tooling flexibility on a compact machine size optimized for small diameter processing.
The 6-spindle unit with Y2-axis control for backworking has two spindles in three rows and can mount up to four power-driven tool units in their respective positions. This enhanced multi-processing capability in backworking will contribute to reducing cycle times through the efficient splitting of processes.
WORKPIECE |
||
|---|---|---|
| DIAMETER |  |
10mm |
| LENGTH |  |
105mm |
| GEOMETRY |  |
|
| C AXIS |  |
MAIN + SUB SPINDLE |
Benefits
- High speed processing with 35m/min rapid rates
- Main spindle speed 15,000 rpm, sub-spindle speed 12,000 rpm
- Z1 Stroke of 105mm
- 10.4" Colour display for user friendly operation
- 6 Station sub-spindle platen for maximum overlapping
- Compact footprint & ergonomic design
Specification
| MAIN SPINDLE SIDE | |
|---|---|
| Number of axes | 8 |
| Main spindle (headstock) | Z1 / C1 axis |
| Main spindle Platen | X1 / Y1 axis |
| Max. machining diameter | 10 mm |
| headstock stroke | 105 mm |
| Main spindle power | 5.5 KW |
| main spindle speed | 15,000 rpm |
| Main spindle tooling | |
| Turning tool | 6 tools @ 10 mm SQ |
| Drilling arm sleeve holder capacity | 4 x Ø 16 MM SLEEVES (ER11) |
| power driven tool (PDT) positions | 5 tools |
| Max (PDT) Speed | 12,000 rpm |
| KINEMATIC DIAGRAM |
|---|
 |
| SUB SPINDLE SIDE | |
|---|---|
| Sub spindle | X2 / Y2 / Z2 / C2 axis |
| Max. chucking diameter | 10 mm |
| sub spindle power | 1.1 kW |
| sub spindle speed | 12,000 rpm |
| Sub spindle tooling | |
| back-working platen positions | 6 |
| max drill sleeve capacity | ER11 / ER16 |
| power driven tool (PDT) positions | 4 (ER11 / ER16) |
| max (pdt) speed | 12,000 RPM |
| FMB | BAR FEED DIMENSION A (MM) | ||
|---|---|---|---|
| Micromag 08-20 | 3415 (1.6M) | 5015 (3.2M) | 6015 (4.2M) |
| Minimag 2-20 | 3415 (1.6M) | 5015 (3.2M) | 6015 (4.2M) |
| Turbo 2-20 | 3215 (2.2M) | 4215 (3.2M) | 5215 (4.2M) |
